The BSW 250 is a high-output moving head combining beam, spot, and wash in one compact fixture. CMY color mixing, a motorized 3°–35° zoom, dual prisms, 10 static and 7 rotating gobos, and linear frost give you complete creative range — from razor-sharp aerial beams to soft, even washes. 540°/270° pan/tilt with 16-bit resolution and automatic repositioning ensure smooth, precise movement. Bright. Flexible. Reliable. Built for stages, clubs, touring, and events where performance cannot be compromised.
| Parameter | Value |
|---|---|
| Product Type | LED Beam Spot Wash Moving Head |
| Light Source | 1 × 250W high-output white LED |
| Color Temperature | 7,000 K |
| Beam Angle | 3° – 35° motorized zoom |
| Function Modes | Beam, Spot, Wash |
| Pan / Tilt | 540° / 270° (16-bit resolution) |
| Color Wheel | 8 colors + open |
| Color Mixing | CMY color mixing |
| Gobos | 10 static + 7 rotating + open |
| Prism | 8-facet & 16-facet rotating prisms |
| Dimmer | 0 – 100% electronic dimming |
| Strobe | 1 – 25 Hz |
| Control Protocols | DMX512, RDM |
| DMX Channels | 18 / 22 / 26 CH |
| Input Voltage | AC 100 – 240 V, 50/60 Hz |
| Power Consumption | 350 W max |
| Connectors | PowerCON in/out, 3-pin XLR in/out |
| Dimensions | 360 × 260 × 500 mm |
| Net Weight | 12.5 kg |
